R&D Center

R&D Equipment

E/G Dynamo & Anechoic Chamber

Test list
  • Muffler Noise Test
  • Muffler Back Pressure Test
Engine Dynamometer (2set) Capacity : 250 kW / 330 kW AC
Anechoic Chamber (KOLAS 인증) Capacity : 8(L)X8(W)X4.6(H)m
ambient noise : 25dBA

  • Engine Dynamo

  • Back Pressure

  • Anechoic Chamber

  • Exhaust Noise

  • Noise Measurement

Ordinary temperature/High Temperature Stress Test

Test list
  • Engine Durability Test
  • Surface Temperature/Back Pressure Test

  • Surface temperature, High Temperature Stress Test

  • Back Pressure Measurement for Position

  • Engine Durability Test

  • Back Pressure Measurement

  • Stress Measurement

  • Surface Temperature Measurement

NVH Test

Test list
  • NVH Test(Muffler, Interior)
  • Modal(Vibration) Analysis
  • Impact Hammer Test
Test Lab - Mobile FFT : LMS
- Normal FFT : LMS
- Microphone, Accelerometer
- Impact Hammer : Vibration Response Test

Muffler Noise Test(Interior, Exhaust Noise)

- Contribution Test for Muffler, TL Test

Modal Analysis of Muffler System

- Mode Shape for Muffler

Muffler Impact Hammer Test

- Muffler Impact Hammer Test(Radiation Prevention)

Thermal Shock Test

Test Lab
  • Thermal Shock Test
  • Thermal Fatigue Test
Specifications Burner - Capacity : 1,000kg/hr, LPG / Control temperature : Max 1,100℃
Chamber - Water Spray : 12EA

  • Thermal Shock Test
    Heating+Quenching(Water Spray)

  • Thermal Fatigue Test
    (Hot End)

  • Water Spray

Thermal Fatigue Tester

Test Lab
  • Thermal Fatigue Test
  • Principle test
Specifications Burner - Capacity : 750kg/hr , LPG / Control temperature : Max 1,000℃

Electric Shaker

Test Lab
  • Hot Vibration Test
  • Cold Vibration Test
  • Component fatigue Test
  • Resonance frequency detection Test
Specifications Electric Shake - Capacity : 2,000Hz, 6,000kgf / Mode : Sine, Random, Shock

  • INPUT - Sine, Sine On Random, Shock

  • Hot/Cold Vibration Test

2-Axis Component Durability Tester

Test Lab
  • 2-Axis Component Durability Test
  • Other Fatigue Endurance test
Specifications Actuator - Displacemen Stroke : MAX ±50mm / Test load : MAX 5kN, 8Hz
Hydraulics Unit - Flux : MAX 113L/min / Test pressure : 21MPa

INPUT - RLD Acceleration Endurance Profile, (PG road surface data)/ sine wave, alternating load

Air Flow Tester

Test Lab
  • Back Pressure Test
  • Drainage Test
  • Flow Noise Test
Air Flow Capacity : 750kg/hr
Mode : Auto Test, DAS

  • Flow Measurement
    - Constant Temperature / Flow Rate

  • Flow Resistance
    - Flow & Flow Resistance

Flow Resistance Measurement

- Back Pressure Test / Drainage Test / Flow Noise

Material Analysis

Stereoscopic Microscope 6.7~45x(continuous)
Metallurgical Microscope 50~1,000x(5step)
Micro Vickers Hardness Tester 50x, 500x, 10~1,000gf(8step)
XRF(X-ray fluorecence) Si(14) to U(92)

  • Stereoscopic Microscope

  • Metallurgical Microscope

  • Micro Vickers Hardness Tester

  • XRF(X-ray fluorecence)

  • Fine Cutter

  • Mounting Press

Stereoscopic Microscope

A. Weld quality Inspection

B. Fracture Inspection

Metallurgical Microscope

A. Weld/Base material Inspection

  • Solid Wire
  • Pipe Weldin
  • Cast iron Welding

B. Crack Inspection

  • Weld boundary Crack
  • Pipe forming part Crack
  • Weld thermal fatigue Crack

C. 부식량/코팅층 두께 조사

  • XM Corrosion-durable finished product
  • Enclosure AI coating layer

Microvickers Hardness Tester

- Measurement of weld and base metal hardness

XRF(X-ray fluorescence)

- Component analysis
